Control: FANUC 0i-TD
YOM: 2014
B-axis Max: 830°
X-axis Travel: 243 mm
Y-axis Travel: 50 mm
Z-axis Travel: 740 mm
Technical Specification
Max. Workpiece Diameter: 350 mm
Spindle Speed: 4000 RPM
Additional Information
Max. Bar passage: Ø 64 mm
Tool turret: 12 positions
Tool attachment: bmt-65
Counterspindle speed: 6–6000 rpm
Spindle nose: a2-8
Counterspindle nose: a2-5
Machine Depth: 2080 mm
Machine Weight: 9600 kg
The Romi GL 350B CNC turning centre is a high-performance machine designed for precision turning in medium to high-production environments. Combining robust construction, advanced CNC control, and excellent machining flexibility, the GL 350B is ideal for subcontract engineering, precision component manufacture, and general industrial machining applications.
Engineered with a rigid cast iron structure, the Romi GL 350B delivers excellent stability and vibration resistance during demanding machining operations. Its heavy-duty design ensures consistent accuracy, high-quality surface finishes, and reliable long-term performance, even under continuous production workloads.
The machine’s thermal and geometric stability further enhances machining precision, making it suitable for high-tolerance turning applications.
The GL 350B offers a maximum turning diameter of approximately 350mm and a turning length of up to 740mm, providing excellent versatility for machining medium-sized components. Axis travels of around 243mm (X-axis) and 740mm (Z-axis) allow for efficient and accurate machining across a wide range of workpieces.
Its large spindle bore and substantial work envelope make the machine suitable for both bar work and larger chucking applications.
Equipped with a high-speed spindle capable of up to 4000 rpm, the Romi GL 350B provides the power and flexibility needed to machine a variety of materials efficiently. The A2-8 spindle nose and generous spindle bore ensure compatibility with common tooling and bar capacities.
The machine’s robust spindle design supports demanding cutting operations while maintaining excellent accuracy and repeatability.
Typically fitted with the reliable FANUC 0i-TD CNC control system, the GL 350B offers user-friendly programming, fast processing, and dependable workshop performance. A 12-station turret allows for quick tool changes and improved machining efficiency, reducing downtime between operations.
This combination of CNC capability and tooling flexibility makes the machine suitable for both batch production and more complex turning operations.
Romi machines are widely recognised for their solid build quality and dependable machining performance in industrial environments. Operators and machinists often value their straightforward operation and durability for everyday production use.
